Foam glass
| Place of Origin | Changzhou, Jiangsu,China |
|---|---|
| Brand Name | JSHESOL |
| Certification | SGS |
| Minimum Order Quantity | 20 Cubic Meters |
| Price | Negotiable |
| Packaging Details | Carton packaging/Wooden case packaging/according to the requirements |
| Delivery Time | Negotiable |
| Payment Terms | EXW/FOB/CIF |
| Supply Ability | According to products |
Product Details
| Environmental Friendly | Yes | Material | Glass |
|---|---|---|---|
| Fire Rating | Class A | Application Temperature | -200°C To 400°C |
| Moisture Resistance | Yes | Installation Method | Adhesive Or Mechanical Fasteners |
| Compressive Strength | ≥0.3 MPa | Insulation Type | Foam |
| Sound Absorption | ≥0.6 | Service Temperature | -200°C To 400°C |
| Thermal Conductivity | 0.036 W/mK | Density | 120 Kg/m3 |
| Chemical Resistance | Yes | Water Absorption | ≤1% |
| Highlight | foam glass pipe insulation,cellular glass insulation material,foam glass thermal insulation |
||
Product Description
Foam Glass Insulation Material
Introduction
Foam glass is an advanced inorganic cold insulation material primarily composed of glass mixed with foaming agents. It undergoes high-temperature foaming in a kiln followed by annealing and cooling, resulting in a uniform structure of independent closed cells.
Applications
- Load-bearing cold insulation for large storage tank bottoms
- Low-temperature frozen pipes and container tanks
- Offshore oil platforms
- Heating pipes and equipment
- Building insulation and energy conservation
Key Features
- Low density, low thermal conductivity, and high compressive strength
- Waterproof, moisture-resistant, and leak-proof
- Minimal thermal expansion with excellent dimensional stability
- Fireproof, non-combustible, and corrosion-resistant
- Resistant to mildew, pests, and microorganisms
- Suitable for extreme environments (high/low temperatures, humidity)
- Easy to cut, process, and install
- Inorganic composition ensures long-term performance without degradation
- Environmentally friendly, recyclable, and non-toxic
Performance Specifications
| Item | Performance Index | Test Mode |
|---|---|---|
| Volume density (Kg/m3) | ≤120 | ≤140 | ≤160 | ≤180 | JC/T 647 |
| Thermal conductivity W/(m*k) | ≤0.042 | ≤0.045 | ≤0.058 | ≤0.062 | GB/T 10294 |
| Compressive strength (MPa) | ≥0.5 | ≥0.6 | ≥0.6 | ≥0.7 | GB/T 5486 |
| Water absorption by volume (%) | ≤0.5 | JC/T 647 |
| Combustibility | A1 | GB 8624 |
Temperature Range
Foam glass insulation systems provide solutions for a wide range of applications at operating temperatures from -268°C to 482°C (-450°F to 900°F).
