Defense Works Foam Glass Insulation Inorganic Rigid Cellular Glass Block Insulation
| Place of Origin | Changzhou, Jiangsu,China |
|---|---|
| Brand Name | Kaff Rees |
| Certification | SGS |
| Minimum Order Quantity | 20 Cubic Meters |
| Price | Negotiable |
| Packaging Details | Carton packaging/Wooden case packaging/according to the requirements |
| Delivery Time | Negotiable |
| Payment Terms | EXW/FOB/CIF |
| Supply Ability | According to products |
Product Details
| Name | Cellular Glass Block Insulation | Feature | Environmental Protection |
|---|---|---|---|
| Dimensional Stability | ≤0.3 | Tensile Strength Vertical To The Plane | ≥0.15 |
| Combustibility | A1 | Application | Petroleum Industry |
| Highlight | Inorganic Rigid Cellular Glass Block Insulation,Defense Works Foam Glass Insulation |
||
Product Description
Defense Works Foam Glass Insulation Inorganic Rigid Cellular Glass Block Insulation
Cellular glass is an inorganic rigid insulation material that is non-toxic, environmentally friendly, and suitable for both cryogenic and high-temperature environments. It is recognized as the most comprehensive low-temperature thermal insulation solution available.
This versatile material serves as both cold and thermal insulation, maintaining performance from deep cold to thermal states without deterioration. Its exceptional durability makes it ideal for harsh environments including low temperature applications, underground engineering, and areas prone to fire, moisture, or chemical erosion. Cellular glass is often referred to as a "permanent thermal insulation material that never requires replacement."
Key Features
- Low density with low thermal conductivity and high compressive strength
- Completely waterproof with no moisture permeability or leakage
- Excellent dimensional stability with minimal thermal expansion
- Fireproof, non-combustible, and corrosion resistant
- Resistant to mildew, pests, and microorganisms
- Suitable for extreme environments including high temperature, deep cold, and constant humidity
- Easy to cut, shape, and install
- Inorganic composition ensures no aging or performance degradation
- 100% recyclable and environmentally safe
Performance Specifications
| Item | Performance Index | Test Mode |
|---|---|---|
| Volume density Kg/m3 | ≤120 | ≤140 | ≤160 | ≤180 | JC/T 647 |
| Conductivity W/(m*k) | ≤0.042 | ≤0.045 | ≤0.058 | ≤0.062 | GB/T 10294 |
| Compressive strength (MPa) | ≥0.5 | ≥0.6 | ≥0.6 | ≥0.7 | GB/T 5486 |
| Flexural strength (MPa) | ≥0.3 | ≥0.5 | ≥0.5 | ≥0.6 | |
| Water Absorption by Vol. (v/v),% | ≤0.5 | JC/T 647 |
| Combustibility | A1 | GB 8624 |
Technical Specifications by Grade
| Property | Unit | Grade 800 | Grade 1000 | Grade 1200 | Grade 1600 |
|---|---|---|---|---|---|
| Ave. Density | kg/m3 | 120±8 | 130±8 | 140±8 | 160±10 |
| Thermal Conductivity (Ave. Value) | W/(m*K) | 0.043 | 0.044 | 0.046 | 0.048 |
| Compressive Strength (Ave. Value) | MPa | 0.8 | 1 | 1.2 | 1.6 |
Applications
Cellular glass insulation is widely used in petroleum, chemical, and pharmaceutical industries, as well as in underground engineering, shipbuilding, and defense applications. It is particularly effective for:
- Cryogenic insulation systems in pharmaceutical facilities
- Hydrocarbon processing systems
- Low temperature piping, equipment, and storage tanks
- Cold storage facilities and refrigeration buildings
- Liquid oxygen and nitrogen storage systems
- Exterior wall, roof, and basement insulation
