| Brand Name: | Kaff Rees |
| MOQ: | 20 Cubic Meters |
| Price: | Negotiable |
| Payment Terms: | EXW/FOB/CIF |
| Supply Ability: | According to products |
Cellular glass is a kind of inorganic rigid insulation materials, which is non-toxic, harmless, environmentally and friendly. It can be applied to cryogenic and high-temperature environment, and it is the best comprehensive low-temperature thermal insulation material.
Cellular glass is not only a cold insulation but also a thermal insulation material, which can be used from deep cold area to thermal state. After long-term use it will not deteriorate and plays an important role in fire prevention and earthquake prevention. It is safe, reliable, and durable when used in harsh environments of low temperature, deep cold, underground engineering, inflammable, explosive, humid and chemical erosion conditions. It is known as "permanent thermal insulation material that does not need to be replaced".
| Item | Performance Index | Test Mode |
|---|---|---|
| Volume density Kg/m3 | ≤120 | ≤140 | ≤160 | ≤180 | JC/T 647 |
| Density range | ＞100 ≤120 | ＞120 ≤140 | ＞140 ≤160 | ＞160 ≤180 | |
| Conductivity W/(m*k) | ≤0.042 | ≤0.045 | ≤0.058 | ≤0.062 | GB/T 10294 |
| Compressive strength (MPa) | ≥0.5 | ≥0.6 | ≥0.6 | ≥0.7 | GB/T 5486 |
| Flexural strength (MPa) | ≥0.3 | ≥0.5 | ≥0.5 | ≥0.6 | |
| Tensile strength vertical to the plane(MPa) | ≥0.15 | JG149 |
| Water Absorption by Vol. (v/v),% | ≤0.5 | JC/T 647 |
| Dimensional stability % | ≤0.3 | GB/T 8811 |
| Combustibility | A1 | GB 8624 |
| Radionuclide limit | internal exposure index(Ira) ≤1.0 | external exposure index(Ir) ≤1.0 | GB 6566 |
| Property | Unit | Grade 800 | Grade 1000 | Grade 1200 | Grade 1600 |
|---|---|---|---|---|---|
| Ave. Density | kg/m3 | 120±8 | 130±8 | 140±8 | 160±10 |
| Thermal Conductivity | W/(m*K) | 0.043 | 0.044 | 0.046 | 0.048 |
| Compressive Strength | MPa | 0.8 | 1 | 1.2 | 1.6 |
| Water Absorption by Vol. | % | ≤0.5 | |||
| Thermal Expansion Coefficient | 1/℃ | 9×10-6 | |||
| Service Temp. | ℃ | -196～+450 | |||
| Property | Unit | Grade 500 | Grade 700 | Grade 1400 | Grade 2400 |
|---|---|---|---|---|---|
| Ave. Density | kg/m3 | 110±8 | 115±8 | 150±10 | 220±20 |
| Thermal Conductivity | W/(m*K) | 0.038 | 0.04 | 0.047 | 0.056 |
| Compressive Strength | MPa | 0.5 | 0.7 | 1.4 | 2.4 |
| Water Absorption by Vol. | % | ≤0.5 | |||
| Thermal Expansion Coefficient | 1/℃ | 9×10-6 | |||
| Service Temp. | ℃ | -196～+450 | |||
