PIR Cavity Wall Insulation Board
| Place of Origin | Changzhou, Jiangsu,China |
|---|---|
| Brand Name | JSHESOL |
| Certification | SGS |
| Minimum Order Quantity | 20 Cubic Meters |
| Price | Negotiable |
| Packaging Details | Carton packaging/Wooden case packaging/according to the requirements |
| Delivery Time | Negotiable |
| Payment Terms | EXW/FOB/CIF |
| Supply Ability | According to products |
Product Details
| Operating Temperature Range | -40°C To 120°C | Thermal Conductivity | 0.02 W/mK |
|---|---|---|---|
| Material | Polyisocyanurate Foam | Fire Rating | Class 1 |
| Insulation Type | Pipe Insulation | Installation Method | Self-adhesive Or Mechanical Fastening |
| Density | 30 Kg/m3 | Uv Resistance | Excellent |
| Compressive Strength | 150 KPa | Moisture Absorption | 0.2% By Volume |
| Water Vapor Permeability | 0.03 Ng/Pa.s.m2 | Length | 6 Feet (1.8 Meters) |
| Chemical Resistance | Resistant To Most Chemicals | Sound Absorption | Excellent |
| Highlight | PIR cavity wall insulation board,thermal insulation board for walls,rigid PIR insulation board |
||
Product Description
PIR Cavity Wall Insulation Board
Product Overview
PIR Cavity Wall Insulation Board is a high-efficiency thermal insulation material specifically designed for cavity spaces in building envelopes. Utilizing polyisocyanurate (PIR) as the core material, this product forms a continuous, thermal bridge-free insulation layer that effectively blocks heat transfer and prevents energy loss.
Key Advantages
- Precise Cavity Fit Available in multiple thickness specifications with tongue-and-groove design for complete sealed insulation, effectively eliminating thermal bridging.
- Excellent Thermal Performance Ultra-low thermal conductivity (≤0.022 W/(m*K)) significantly enhances wall insulation, reducing building energy consumption and helping achieve passive building standards.
- Long-lasting Moisture Resistance High closed-cell content (≥96%) structure resists moisture intrusion, remaining non-absorbent and non-deformable for lasting performance.
- Safe and Environmentally Reliable Meets B1 flame-retardant standard with excellent fire performance and no harmful substance release.
Key Technical Parameters
| Test Item | Unit | Technical Data | Test Standard |
|---|---|---|---|
| Standard Thickness | mm | 25/40/50/75/100 | - |
| Thermal Conductivity | W/(m*K) | ≤0.022 | EN 12667 |
| Density | kg/m³ | 35-45 | EN 1602 |
| Tensile Strength | kPa | ≥80 | EN 1607 |
| Dimensional Stability | % | ≤1.0 | EN 1604 |
| Water Absorption | % | ≤1.0 | EN 12087 |
| Fire Rating | - | B1 Class | EN 13501-1 |
Applications
- Insulation systems for cavity walls in new residential and commercial buildings
- Energy-efficient retrofitting of existing buildings
- Passive house and low-energy building projects
- Thermal insulation for industrial plants and warehouses
Why Choose Us
- Professional Solutions Specifically developed for cavity wall characteristics, solving challenges like settling and poor sealing of traditional materials.
- Significant Energy Savings Reduces building energy consumption by 30%-50% with short investment payback period.
- Quality Assurance System Fully automated production ensures stable quality with complete certification documents.
- Comprehensive Service Support Technical calculations, solution design, and installation guidance for smooth project implementation.
Installation Guidelines
- Precisely measure cavity dimensions before construction
- Ensure tight seams during installation to avoid gaps
- Protect board surfaces from performance-affecting damage
- Follow construction specifications for system integrity
This product provides durable and efficient thermal insulation solutions with exceptional performance and reliable quality for modern building cavity wall insulation systems.
