B1 Grade Flame Retardant Polyisocyanurate Insulation Board 30 Kg/M3 Density

Brand Name:	JSHESOL
MOQ:	20 Cubic Meters
Price:	Negotiable
Payment Terms:	EXW/FOB/CIF
Supply Ability:	According to products

Detail Information

Product Description

Detail Information

Place of Origin:

Changzhou, Jiangsu,China

Certification:

SGS

Operating Temperature Range:

-40°C To 120°C

Thermal Conductivity:

0.02 W/mK

Material:

Polyisocyanurate Foam

Fire Rating:

Class 1

Insulation Type:

Pipe Insulation

Installation Method:

Self-adhesive Or Mechanical Fastening

Density:

30 Kg/m3

Uv Resistance:

Excellent

Compressive Strength:

150 KPa

Moisture Absorption:

0.2% By Volume

Water Vapor Permeability:

0.03 Ng/Pa.s.m2

Length:

6 Feet (1.8 Meters)

Chemical Resistance:

Resistant To Most Chemicals

Sound Absorption:

Excellent

Packaging Details:

Carton packaging/Wooden case packaging/according to the requirements

Highlight:

Flame Retardant Polyisocyanurate Insulation Board

B1 Grade Flame Retardant Insulation Board

Polyisocyanurate Insulation Board 30 Kg/M3 Density

Product Description

B1 Grade Flame Retardant Polyisocyanurate Insulation Board 30 Kg/M3 Density

Product Overview

This high-performance polyisocyanurate insulation board meets the national B1 grade flame retardant standard. Manufactured using advanced PIR material through special formulation processes, it offers excellent thermal insulation performance and outstanding fire safety characteristics. Its unique molecular structure forms a dense char layer when exposed to fire, effectively preventing flame spread while maintaining low smoke density and toxic gas emissions, providing comprehensive safety protection for buildings.

Core Advantages

Exceptional Fire Performance: Certified with national B1 grade flame retardant standard, featuring low smoke and low toxicity characteristics, non-dripping when exposed to fire, effectively inhibiting flame propagation.
High Thermal Efficiency: Closed-cell content over 95%, thermal conductivity as low as 0.022W/(m*K), effectively preventing heat transfer, significantly reducing building energy consumption.
Stable Physical Properties: Excellent dimensional stability and compressive strength, maintaining structural integrity even in harsh environments.
Environmentally Friendly and Safe: Free from harmful substances such as formaldehyde, environmentally friendly in both production and use.

Technical Parameters

Test Item	Unit	Technical Data	Test Standard
Fire Rating	-	B1 Class	GB 8624
Thermal Conductivity	W/(m*K)	≤0.022	GB/T 10295
Density	kg/m³	40-45	GB/T 6343
Compressive Strength	kPa	≥200	GB/T 8813
Dimensional Stability	%	≤1.0	GB/T 8811
Water Absorption	%	≤1.5	GB/T 8810
Smoke Density Rating	-	≤65	GB/T 8627

Applications

Public buildings with special fire safety requirements
Commercial complexes and high-rise buildings
Industrial plants and storage facilities
Transportation sector
Energy efficiency retrofit projects for existing buildings

Why Choose Us

Dual Safety Assurance: Meets both building energy efficiency requirements and provides reliable fire protection.
Trustworthy Quality: Fully automated production lines combined with strict quality control systems.
Professional Technical Support: Comprehensive services from solution design to installation guidance.
Complete Service System: Rapid supply capacity and timely after-sales response.
