Safe Thermal Insulation Foam Glass Board Easy Processing For Defense Works

Brand Name:	Kaff Rees
MOQ:	20 Cubic Meters
Price:	Negotiable
Payment Terms:	EXW/FOB/CIF
Supply Ability:	According to products

Detail Information

Product Description

Detail Information

Place of Origin:

Changzhou, Jiangsu,China

Certification:

SGS

Name:

Cellular Glass Board Insulation

Feature:

Environmental Protection

Dimensional Stability:

≤0.3

Tensile Strength Vertical To The Plane:

≥0.15

Combustibility:

Application:

Petroleum Industry

Packaging Details:

Carton packaging/Wooden case packaging/according to the requirements

Highlight:

foam glass thermal insulation

cellular glass board

Product Description

Safe Thermal Insulation Foam Glass Board

Foam glass insulation features a homogeneous, closed-cell glass structure that resists moisture in both liquid and vapor forms, ensuring long-term, consistent insulating efficiency.

As an inorganic rigid insulation material, cellular glass is non-toxic, environmentally friendly, and suitable for both cryogenic and high-temperature environments. It represents the most comprehensive low-temperature thermal insulation solution available.

This versatile material serves as both cold and thermal insulation, maintaining performance from deep cold to thermal states without deterioration. Its exceptional durability makes it ideal for fire prevention, earthquake resistance, and use in harsh environments including low-temperature applications, underground engineering, and areas with chemical exposure or high humidity.

Key Features

Low density with high compressive strength and minimal thermal conductivity
Completely waterproof with no moisture permeability
Excellent dimensional stability with minimal thermal expansion
Fireproof, non-combustible, and corrosion resistant
Resistant to mold, pests, and microorganisms
Performs reliably in extreme temperature and humidity conditions
Easy to cut and install with simple processing requirements
Inorganic composition ensures no aging or performance degradation
100% recyclable and environmentally safe

Performance Specifications

Standard Performance Metrics
Item	Performance Index	Test Mode
Volume density (Kg/m3)	≤120 \| ≤140 \| ≤160 \| ≤180	JC/T 647
Conductivity (W/(m*k))	≤0.042 \| ≤0.045 \| ≤0.058 \| ≤0.062	GB/T 10294
Compressive strength (MPa)	≥0.5 \| ≥0.6 \| ≥0.6 \| ≥0.7	GB/T 5486
Flexural strength (MPa)	≥0.3 \| ≥0.5 \| ≥0.5 \| ≥0.6
Water Absorption by Vol. (v/v,%)	≤0.5	JC/T 647
Combustibility	A1	GB 8624

Grade-Specific Properties
Property	Unit	Grade 800	Grade 1000	Grade 1200	Grade 1600
Ave. Density	kg/m3	120±8	130±8	140±8	160±10
Thermal Conductivity (Ave. Value)	W/(m*K)	0.043	0.044	0.046	0.048
Compressive Strength (Ave. Value)	MPa	0.8	1	1.2	1.6
Service Temp.	℃	-196～+450

Applications

This advanced thermal insulation material is widely used in:

Petroleum and chemical industries
Underground engineering and defense works
Shipbuilding and pharmaceutical cryogenic systems
Hydrocarbon processing and low-temperature piping
Storage tanks, cold storage facilities, and buildings
Liquid oxygen/nitrogen systems and exterior wall insulation

Production Process
