No Degradation Cellular Glass Inorganic Heat Insulating Material For Harsh Environments
| Place of Origin | Changzhou, Jiangsu,China |
|---|---|
| Brand Name | Kaff Rees |
| Certification | SGS |
| Minimum Order Quantity | 20 Cubic Meters |
| Price | Negotiable |
| Packaging Details | Carton packaging/Wooden case packaging/according to the requirements |
| Delivery Time | Negotiable |
| Payment Terms | EXW/FOB/CIF |
| Supply Ability | According to products |
Product Details
| Name | Cellular Glass Board Insulation | Feature | Environmental Protection |
|---|---|---|---|
| Dimensional Stability | ≤0.3 | Tensile Strength Vertical To The Plane | ≥0.15 |
| Combustibility | A1 | Application | Petroleum Industry |
| Highlight | Cellular Glass Heat Insulating Material,No Degradation cellular glass board |
||
Product Description
No Degradation Cellular Glass Inorganic Heat Insulating Material For Harsh Environments
Foamglass insulation is 100% glass and contains no binders or fillers - it cannot burn. It will not absorb flammable liquids or vapors. Cellular glass is a kind of inorganic rigid insulation materials, which is non-toxic, harmless, environmentally and friendly. It can be applied to cryogenic and high-temperature environment, and it is the best comprehensive low-temperature thermal insulation material.
Key Features
- Low density, low thermal conductivity and high compressive strength
- No water absorption, moisture permeability and leakage
- Small thermal expansion coefficient, good dimensional stability, no deformation and no cracking
- Fire protection, non combustion and corrosion resistance
- No mildew, no mouse sniffing, pest control and microorganism
- Suitable for all kinds of harsh environments such as high temperature, deep cold, constant temperature and humidity
- Easy to cut, process and construct
- Inorganic products, no aging, no degradation of performance, service life synchronous with buildings
- Recycling, innocuity, safety and environmental protection
Performance Index
| Item | Performance Index | Test Mode |
|---|---|---|
| Volume density Kg/m3 | ≤120 | ≤140 | ≤160 | ≤180 | JC/T 647 |
| Density range | ＞100 ≤120 | ＞120 ≤140 | ＞140 ≤160 | ＞160 ≤180 | |
| Conductivity W/(m*k) | ≤0.042 | ≤0.045 | ≤0.058 | ≤0.062 | GB/T 10294 |
| Compressive strength (MPa) | ≥0.5 | ≥0.6 | ≥0.6 | ≥0.7 | GB/T 5486 |
| Flexural strength (MPa) | ≥0.3 | ≥0.5 | ≥0.5 | ≥0.6 | |
| Tensile strength vertical to the plane(MPa) | ≥0.15 | JG149 |
| Water Absorption by Vol. (v/v),% | ≤0.5 | JC/T 647 |
| Dimensional stability % | ≤0.3 | GB/T 8811 |
| Combustibility | A1 | GB 8624 |
| Radionuclide limit | internal exposure index(Ira) ≤1.0 | external exposure index(Ir) ≤1.0 | GB 6566 |
Technical Specifications
| Property | Unit | Grade 800 | Grade 1000 | Grade 1200 | Grade 1600 |
|---|---|---|---|---|---|
| Ave. Density | kg/m3 | 120±8 | 130±8 | 140±8 | 160±10 |
| Thermal Conductivity | W/(m*K) | 0.043 | 0.044 | 0.046 | 0.048 |
| Compressive Strength | MPa | 0.8 | 1 | 1.2 | 1.6 |
| Water Absorption by Vol. | % | ≤0.5 | |||
| Thermal Expansion Coefficient | 1/℃ | 9×10-6 | |||
| Service Temp. | ℃ | -196～+450 | |||
Applications
As an advanced thermal insulation material, cellular glass is widely used in petroleum industry, chemical industry, underground engineering, shipbuilding and defense works. It can be used in the cryogenic insulation system in pharmacy, the cryogenic system in hydrocarbon processing, the low temperature piping, equipment and storage tank, the cold storage and cold storage building, the steel liquid oxygen, liquid nitrogen storage tank and pipeline, and exterior wall insulation, exterior insulation, roofing, basement.
Production Flow
