Petroleum Industry Thermal Insulation Foam Glass Board Fire Protection OEM
| Place of Origin | Changzhou, Jiangsu,China |
|---|---|
| Brand Name | Kaff Rees |
| Certification | SGS |
| Minimum Order Quantity | 20 Cubic Meters |
| Price | Negotiable |
| Packaging Details | Carton packaging/Wooden case packaging/according to the requirements |
| Delivery Time | Negotiable |
| Payment Terms | EXW/FOB/CIF |
| Supply Ability | According to products |
Product Details
| Name | Thermal Insulation Foam Glass Board | Feature | Fire Protection |
|---|---|---|---|
| Dimensional Stability | ≤0.3 | Tensile Strength Vertical To The Plane | ≥0.15 |
| Combustibility | A1 | Application | Petroleum Industry |
| Highlight | Thermal Insulation Foam Glass Board,OEM cellular glass board |
||
Product Description
Petroleum Industry Thermal Insulation Foam Glass Board Fire Protection OEM
Reliable Application Service
- Tank Base Bearing and Insulation for Big Volume Tank
- Low Temperature and Cryogenic Piping, Vessel, Tank and Equipment
- Underground or Aboveground Steam Piping and Chilled Water Piping
- Chilled or Hot Water Supplying Piping
- Offshore Oil Platform
- Circulation and Dual Temperature System
- Heating Piping and Equipment
- Hot Oil or Asphalt Tank
- Liquid Heat Exchanger System
- Insulation & Acid-resistant Lining System for Chimney in Power Plant
- Insulation & Energy-saving for Building
Key Features
- Low density, low thermal conductivity and high compressive strength
- No water absorption, moisture permeability or leakage
- Small thermal expansion coefficient with excellent dimensional stability
- Fire protection, non-combustible and corrosion resistant
- Resistant to mildew, pests and microorganisms
- Suitable for harsh environments including high temperature, deep cold, and constant humidity
- Easy to cut, process and install
- Inorganic composition with no aging or performance degradation
- Recyclable, non-toxic, safe and environmentally friendly
Performance Specifications
| Item | Performance Index | Test Mode |
|---|---|---|
| Volume density (Kg/m3) | ≤120 | ≤140 | ≤160 | ≤180 | JC/T 647 |
| Conductivity (W/(m*k)) | ≤0.042 | ≤0.045 | ≤0.058 | ≤0.062 | GB/T 10294 |
| Compressive strength (MPa) | ≥0.5 | ≥0.6 | ≥0.6 | ≥0.7 | GB/T 5486 |
| Flexural strength (MPa) | ≥0.3 | ≥0.5 | ≥0.5 | ≥0.6 | |
| Tensile strength vertical to the plane (MPa) | ≥0.15 | JG149 |
| Water Absorption by Vol. (v/v),% | ≤0.5 | JC/T 647 |
| Dimensional stability % | ≤0.3 | GB/T 8811 |
| Combustibility | A1 | GB 8624 |
| Radionuclide limit | Ira ≤1.0 | Ir ≤1.0 | GB 6566 |
Technical Properties
| Property | Unit | Grade 800 | Grade 1000 | Grade 1200 | Grade 1600 |
|---|---|---|---|---|---|
| Ave. Density | kg/m3 | 120±8 | 130±8 | 140±8 | 160±10 |
| Thermal Conductivity (Ave. Value) | W/(m*K) | 0.043 | 0.044 | 0.046 | 0.048 |
| Compressive Strength (Ave. Value) | MPa | 0.8 | 1 | 1.2 | 1.6 |
| Water Absorption by Vol. | % | ≤0.5 | |||
| Service Temp. | ℃ | -196～+450 | |||
Cellular glass is an inorganic rigid insulation material that is non-toxic, environmentally friendly, and suitable for both cryogenic and high-temperature environments. It offers exceptional performance as a comprehensive thermal insulation solution.
This material serves as both cold and thermal insulation, maintaining its properties from deep cold to thermal states without deterioration. It provides excellent fire and earthquake resistance, making it ideal for harsh environments including low temperature, underground applications, and areas with chemical exposure. Known as a "permanent thermal insulation material," it requires no replacement over time.
