Custom Thick Cellular Glass Insulation Boards Inorganic Heat Insulating Material
| Place of Origin | Changzhou, Jiangsu,China |
|---|---|
| Brand Name | Kaff Rees |
| Certification | SGS |
| Minimum Order Quantity | 20 Cubic Meters |
| Price | Negotiable |
| Packaging Details | Carton packaging/Wooden case packaging/according to the requirements |
| Delivery Time | Negotiable |
| Payment Terms | EXW/FOB/CIF |
| Supply Ability | According to products |
Product Details
| Feature | No Leakage | Dimensional Stability | ≤0.3 |
|---|---|---|---|
| Tensile Strength Vertical To The Plane | ≥0.15 | Name | Cellular Glass Board Insulation |
| Combustibility | A1 | Application | Petroleum Industry |
| Highlight | Heat Insulating Cellular Glass Boards,Custom Thick Cellular Glass Insulation Boards |
||
Product Description
Custom Thick Cellular Glass Insulation Boards
Inorganic Heat Insulating Material
Cellular glass is a nontoxic material with stable chemical properties and excellent thermal insulation performance. It maintains effectiveness across a wide temperature range from cryogenic to high temperatures while providing protection against humidity, fire, and chemical erosion.
Recognized as a "permanent thermal insulating material requiring no renewal," cellular glass demonstrates exceptional durability in harsh conditions including low temperatures, underground environments, outdoor exposure, and chemical exposure. This makes it ideal for permanent installations in petroleum, chemical engineering, construction, refrigeration, shipbuilding, and defense applications.
Key Features
- Low density with minimal thermal conductivity and high compressive strength
- Completely waterproof with no moisture permeability or leakage
- Excellent dimensional stability with minimal thermal expansion
- Fireproof, non-combustible, and corrosion resistant
- Resistant to mildew, pests, and microorganisms
- Suitable for extreme environments including high heat, deep cold, and constant humidity
- Easy to cut, shape, and install
- Inorganic composition ensures no aging or performance degradation
- 100% recyclable and environmentally safe
Performance Specifications
| Item | Performance Index | Test Mode |
|---|---|---|
| Volume density Kg/m3 | ≤120 | ≤140 | ≤160 | ≤180 | JC/T 647 |
| Conductivity W/(m*k) | ≤0.042 | ≤0.045 | ≤0.058 | ≤0.062 | GB/T 10294 |
| Compressive strength (MPa) | ≥0.5 | ≥0.6 | ≥0.6 | ≥0.7 | GB/T 5486 |
| Flexural strength (MPa) | ≥0.3 | ≥0.5 | ≥0.5 | ≥0.6 | |
| Water Absorption by Vol. (v/v),% | ≤0.5 | JC/T 647 |
| Combustibility | A1 | GB 8624 |
| Property | Unit | Grade 800 | Grade 1000 | Grade 1200 | Grade 1600 |
|---|---|---|---|---|---|
| Ave. Density | kg/m3 | 120±8 | 130±8 | 140±8 | 160±10 |
| Thermal Conductivity | W/(m*K) | 0.043 | 0.044 | 0.046 | 0.048 |
| Compressive Strength | MPa | 0.8 | 1 | 1.2 | 1.6 |
Applications
Cellular glass insulation is extensively used in petroleum processing, chemical plants, underground construction, shipbuilding, and defense applications. It serves as ideal insulation for:
- Pharmaceutical cryogenic systems
- Hydrocarbon processing equipment
- Low-temperature piping and storage tanks
- Cold storage facilities
- Liquid oxygen/nitrogen containment
- Building insulation (walls, roofs, basements)
