| Brand Name: | Kaff Rees |
| MOQ: | 20 Cubic Meters |
| Price: | Negotiable |
| Payment Terms: | EXW/FOB/CIF |
| Supply Ability: | According to products |
As an advanced thermal insulation material, cellular glass is widely used in petroleum, chemical, and underground industries, as well as shipbuilding and defense applications. Ideal for cryogenic systems in pharmaceutical and hydrocarbon processing, low temperature piping, equipment storage tanks, cold storage facilities, liquid oxygen/nitrogen storage, and building insulation for walls, roofs, and basements.
Cellular glass serves as both cold and thermal insulation material, effective from deep cold to thermal states. This permanent insulation solution maintains performance without deterioration, offering exceptional fire and earthquake resistance. Its durability makes it reliable for harsh environments including low temperatures, underground applications, and areas with chemical exposure or high humidity.
| Item | Performance Index | Test Mode |
|---|---|---|
| Volume density (Kg/m3) | ≤120 | ≤140 | ≤160 | ≤180 | JC/T 647 |
| Conductivity (W/(m*k)) | ≤0.042 | ≤0.045 | ≤0.058 | ≤0.062 | GB/T 10294 |
| Compressive strength (MPa) | ≥0.5 | ≥0.6 | ≥0.6 | ≥0.7 | GB/T 5486 |
| Flexural strength (MPa) | ≥0.3 | ≥0.5 | ≥0.5 | ≥0.6 | |
| Water Absorption by Vol. (v/v,%) | ≤0.5 | JC/T 647 |
| Combustibility | A1 | GB 8624 |
| Property | Unit | Grade 800 | Grade 1000 | Grade 1200 | Grade 1600 |
|---|---|---|---|---|---|
| Ave. Density | kg/m3 | 120±8 | 130±8 | 140±8 | 160±10 |
| Thermal Conductivity (Ave.) | W/(m*K) | 0.043 | 0.044 | 0.046 | 0.048 |
| Compressive Strength (Ave.) | MPa | 0.8 | 1 | 1.2 | 1.6 |
| Service Temp. | ℃ | -196～+450 | |||
